C.4 Scan Test Targets
With the help of this function, the user can scan either a CSTT target or an IT8 target. The
targets are used to analyze specific features of the scanner’s camera and internal
parameters.
Some CSTT test target are delivered with the scanner.
In the Poweruser main menu screen find the section Adjustments & Support. Select
here Scan Test Targets . Another screen opens.
Select here either Scan CSTT Test Target or Scan IT8 Test Target .
C.4.1 Scan CSTT Test Target
When Scan CSTT Test Target is selected, the next screen shows how to position the
target on the document table.
The CSTT test target can be placed at three position. Select a position corresponding to
the picture on the screen. Click on Next Step to start the test sequence
Picture 68: Position of CSTT target on the document table
The test target will be scanned and the image will be saved to a directory which is defined
by the user. The saved image can be used for support purposes.
Page 58 Setup and Assembly Manual
