Technical specifications
• Physical description
• Dimensions :
- Control cabinet: 1051 mm x 463 mm x 340 mm (41.4" x 18.2" x 13.4")
- Print head: 225 mm x 44.5 mm x 47.5 mm (8.8" x 1.7" x 1.9")
• Weight :
- Control cabinet: 40kg (88.2 lbs)
- Head and conduit: 3kg (6.6 lbs)
• Volume:
- Tanks: Total: 2 liters (3.52pts)
Useful: 1 liter (1.76pts)
• Installation conditions
• Working position:
- Control cabinet: vertical
- Print head: any position
• Max. height difference between head and printer body:
-±2meters(±6.56ft)
• Distance between head and printer body:
- 3 meters (9.8ft), 5 meters (16.4ft), and 8 meters (26.2ft)
(dépending on machine and options)
• Power source
• Electrical :
-100V-240Vac
- Frequency 50 Hz-60 Hz
• Compressed air:
- Min. 5 bar (72 PSI) - Max. 10 bar (145 PSI)
- Flow rate: 800 Nl/h at 7 bars (0.47 Scfm at 101 PSI)
- Air quality: - 0.12 g water/m3 (0.15 oz/cubic foot)
-1PPMoil
- particles < 5 µm
• Limits of use
• Operating temperature:
- 0°C to 50°C (32°F to 122°F)
• Humidity:
-10to90%
