13
Installation types summarised table (Fig. 13):
C
(10)
Appliance with pipes connecting to a horizontal terminal,
which simultaneously allows the inlet of combustion air and the
release of ue gas through concentric orices or close enough to
be in similar wind conditions.
C
(12)
Appliance with pipes connecting to a vertical terminal, which
simultaneously allows the inlet of combustion air and the
release of ue gas through concentric orices or close enough to
be in similar wind conditions.
C
(15)
Appliance with two separate pipes connecting to a collective
conventional ue. e ue consists of two pipes, concentric or
separate, with air intake in one and ue gas release in the other
and are in similar wind conditions.
