5 Transport
Danger!
Lethal injuries with wrong transport by fork lift truck.
Take care of the right position using transport device to avoid
tilting of the system.
Pick up the system only from the side, because centre of gravity
is in the upper front third.
If the fork is too small or too narrow adjusted there is a danger of
system tip over from the mean of transportation.
Please wear appropriate personal protective equipment (PPE).
Let do transportation only by trained personnel.
There is no guarantee for damages because of failure to comply
transport regulations.
> Transport the system always with fork lift truck or pallet truck.
> Please protect the induction coil against damages with sturdy
foam material.
> Transport the system upright. If the machine is transported in an-
other position, the system will be damaged.
> Take up the system from the side.
Figure 26: lifting the weight
