Infineon Technologies TLE5012B - Activation Status Register

TLE5012B
SSC Registers
User’s Manual 79 Rev. 1.2, 2018-02
Activation Status Register
ACSTAT Offset Reset Value
Activation Status Register 01
H
18EE
H
Field Bits Type Description
Res 15:11 res Reserved
Reset: 00011
B
(during operation may change to 01011
B
)
AS_FRST 10 wu Activation of Firmware Reset
All configuration registers retain their contents.
0
B
default or after execution of firmware reset.
Firmware also sets S_RST at this point.
1
B
activation of firmware reset.
Reset: 0
B
AS_ADCT 9 wu Enable ADC Test vector Check
Activation of this test is only allowed with deactivated
AUTOCAL. X, Y and Temp channel will be checked.
0
B
after execution.
1
B
activation of ADC Test vector Check.
Reset: 1
B
(for update buffer 0
B
if no update command
send before)
AS_VEC_MAG 7 wu Activation of Magnitude Check
0
B
monitoring of magnitude disabled
1)
.
1
B
monitoring of magnitude enabled.
Reset: 1
B
(for update buffer 0
B
if no update command
send before)
AS_VEC_XY 6 wu Activation of X,Y Out of Limit-Check
0
B
monitoring of X,Y Out of Limit disabled
1)
.
1
B
monitoring of X,Y Out of Limit enabled.
Reset: 1
B
(for update buffer 0
B
if no update command
send before)
AS_OV 5 wu Enable of DSPU Overflow Check
0
B
monitoring of DSPU Overflow disabled
1)
.
1
B
monitoring of DSPU Overflow enabled.
Reset: 1
B
(for update buffer 0
B
if no update command
send before)
15 8
7 07
AS_DSPU
44
wu
33
AS_FUSE
22
wu
AS_VR
10
w
AS_RST
wu
Reserved
11 10
9
wu wu
AS_FRST
AS_ ADCT
Reserved
AS_VEG_MAG
AS_VEC_XY AS_OV AS_WD
65
wuwuwu wu
