Infineon Technologies TLE5012B - Offset X Register; Offset Y Register

TLE5012B
SSC Registers
User’s Manual 91 Rev. 1.2, 2018-02
Offset X Register
Offset Y Register
OFFX Offset Reset Value
Offset X 0A
H
device-specific
Field Bits Type Description
X_OFFSET 15:4 w Offset Correction of X-value in digits
12-bit signed integer value of raw X-signal offset
correction at 25°C.
Reset: device-specific
OFFY Offset Reset Value
Offset Y 0B
H
device-specific
Field Bits Type Description
Y_OFFSET 15:4 w Offset Correction of Y-value in digits
12-bit signed integer value of raw Y-signal offset
correction at 25°C.
Reset: device-specific
15 8
7 0
15
w
X_OFFSET
74
w
X_OFFSET
30
Res
15 8
7 0
15
w
Y_OFFSET
74
w
Y_OFFSET
30
Res
