TLE5012B
SSC Registers
User’s Manual 93 Rev. 1.2, 2018-02
IFAB Register (multi-purpose)
IFAB Offset Reset Value
IFAB Register 0D
H
device-specific
Field Bits Type Description
ORTHO 15:4 w Orthogonality Correction of X and Y Components
12-bit signed integer value of orthogonality correction.
GMR element orthogonality correction.
+2047
D
11.2445°
0
D
0°
-2048
D
-11.2500°
Reset: device-specific
FIR_UDR 3 w FIR Update Rate
Initial filter update rate (FIR) setting to be loaded into
FIR_MD on startup. Changing of the FIR setting can only
be done by writing to the FIR_MD bits via SPI after
power-on.
0
B
FIR_MD = ‘10’ (85.3 µs)
1
B
FIR_MD = ‘01’ (42.7 µs)
Reset: derivate-specific
IFAB_OD 2 w IFA,IFB,IFC Output Mode
0
B
Push-Pull
1
B
Open Drain
Reset: derivate-specific
15 8
7 0
15
w
ORTHO
74
w
ORTHO
33
w
FIR_UDR
22
w
IFAB_OD
10
w
IFAB_HYST
