TLE5012B
SSC Registers
User’s Manual 94 Rev. 1.2, 2018-02
Interface Mode4 Register (multi-purpose)
IFAB_HYST (multi-purpose) 1:0 w HSM and IIF Mode: Hysteresis
Switching hysteresis on direction change for HSM and IIF
interface.
00
B
0°
01
B
0.175°
10
B
0.35°
11
B
0.70°
SPC Mode: Unit Time
00
B
3.0 µs
01
B
2.5 µs
10
B
2.0 µs
11
B
1.5 µs
Reset: derivate-specific
MOD_4 Offset Reset Value
Interface Mode4 Register 0E
H
device-specific
Field Bits Type Description
TCO_X_T 15:9 w Offset Temperature Coefficient for X-Component
7-bit signed integer value of X-offset temperature
coefficient. This register is used both with autocalibration
and without autocalibration. If autocalibration is
deactivated, overwrite only with the default value. If
autocalibration is activated, do not write this bitfield. See
“Offset temperature compensation” on Page 97.
Reset: device-specific
Field Bits Type Description
15 8
7 0
15 9
w
TCO_X_T
8
w
HSM_PL
P
75
w
HSM_PLP
43
w
IFAB_RES
22
Res
10
w
IF_MD
