InFocus IN5122 User Manual

41
AUDIO menu
AUDIO menu
From the AUDIO menu, items shown in the table below
can be performed. Highlight an item using the ▲/▼
cursor buttons, and press the ► cursor or the SELECT
button to select the item. Then make adjustments per
the following table.
Item Description
VOLUME
Using the ◄/► buttons adjusts the volume.
LOW
ó
HIGH
INTERNAL
SPEAKERS
Using the ▲/▼ buttons turns the built-in speaker on and off.
ENABLE
ó
DISABLE
When DISABLE is selected, the built-in speaker will not work.
AUDIO SOURCE
When the image signal from the input port chosen in step (1) is
projected, the audio signal from the input port selected in step
(2) is output to both the AUDIO OUT port and built-in speaker of
this projector. However, the built-in speaker does not work when
INTERNAL SPEAKERS is set to OFF.
(1) Choose an image input port using the
▲/▼ buttons.
Choose STANDBY to select the sound
output in the power saving mode.
(2) Select one of the
AUDIO IN ports using
◄/► buttons.
Select
to mute the sound from the
input port or in the power saving mode chosen in step (1).
• In the AUDIO SOURCE window, “H” symbolizes the audio signal
from the HDMI port. It can only be selected for the image input from
the HDMI port.
• Even if the projector is in power saving mode, cooling fans may
continue to operate and make noise when the built-in speakers are
in operation.
• CLOSED CAPTIONS is automatically activated when
is selected
and an input signal containing Closed Captioning is received.
This feature is available only when the signal is NTSC for VIDEO
or S-video, or 480i@60 for COMPONENT, COMPUTER IN1 or
COMPUTER IN2, and when AUTO is selected for DISPLAY in the
CLOSED CAPTIONS menu under the SCREEN menu (

48).
(continued on next page)

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
