17
STANDBY/ON SOURCE MENU
SECURITY
LAMP
TEMP
POWER
1.
Make sure that the power cord is rmly
connected correctly to the projector and the
outlet.
Turning on the power
2.
Make sure that the POWER indicator is
steady orange (89). Then remove the lens
cover.
3.
Press STANDBY/ON on the projector or
the remote control.
The projection lamp will light up and the
POWER indicator will begin blinking green. When the
power is completely on, the indicator will stop blinking and become a steady
green (89).
Power on and off
To display an image, select an input signal based on the section Selecting an
input signal (
18).
►A strong light is emitted when the projector’s power is on.
Do not look into the projector lens or look inside the projector through any of the
projector’s openings.
►Do not touch anywhere around the lamp cover or exhaust vents during use or
just after use, since it will be too hot.
WARNING
1.
Press the STANDBY/ON button on the projector or the remote control.
The message “Power off?” will appear on the screen for about 5 seconds.
Turning off the power
2.
Press the STANDBY/ON button again when the message appears.
The projector lamp will go off, and the POWER indicator will begin blinking
in orange. Then the POWER indicator will stop blinking and light a steady
orange when the lamp has cooled completely (89).
3.
Attach the lens cover, after the POWER indicator turns steady orange.
Do not turn the projector on for about 10 minutes or more after turning it off.
Also, do not turn the projector off immediately after turning it on. Doing so may cause
the lamp to malfunction or shorten the lifetime of some parts including the lamp.
STANDBY/ON button
• Turn the power on and off in the correct order. Please power on the
projector prior to the connected devices.
This projector has a feature which can make the projector automatically turn on
and off. Please refer to the AC POWER ON
(49)
and AUTO POWER
(50)
items in the OPTION menu.
NOTE
Power on and off
POWER indicator

Other manuals for InFocus IN5122

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN5122 and is the answer not in the manual?

InFocus IN5122 Specifications

General IconGeneral
Matrix size0.63 \
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)2000:1
Screen size compatibility35.4 - 358 \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
FocusManual
Throw ratio1.5 - 2.5:1
Zoom capabilityYes
Focal length range- mm
Vertical lens shift range-20 - 0 °
Horizontal lens shift range-20 - 20 %
Lamp typeUHP
Lamp power245 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
3D-
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions1600 x 1200 (UXGA)
RMS rated power16 W
Number of built-in speakers2
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Ethernet LAN data rates10, 100 Mbit/s
Cables includedAC, RCA, VGA
Power consumption (standby)- W
Noise level32 dB
CertificationUL, c-UL, FCC, CE
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Cable lock slot typeKensington
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth318.5 mm
Width401 mm
Height111 mm
Weight4800 g
Package depth420 mm
Package width560 mm
Package height197 mm
Package weight8200 g
