76
Presentation tools
PC-LESS Presentation (continued)
Slideshow mode
The following options can be available when the Slideshow is displayed.
* These options are not available when the projector OSD is displayed.
• You cannot change the input ports using the SOURCE button when
the Thumbnail screen, Slideshow, or Full Screen is displayed.
• When the Slideshow mode is set to ONE TIME, the last slide of the
presentation will stay on the screen until the SELECT button on the remote
control or Web Remote Control, or the projector's SOURCE button is pushed.
NOTE
You can start this feature from the Slideshow menu. To display the Slideshow
menu, select the SLIDESHOW button in the Thumbnail mode and press the
SELECT button on the remote control or projector's SOURCE button.
Button operation
Features
The remote
control
The keypad
on the
projector
Web Remote
in web browser
software.
SELECT SOURCE SELECT Displays thumbnail
The Slideshow mode displays images in full screen and switches the images at
intervals set in INTERVAL on the Thumbnail screen menu (71).

Other manuals for InFocus IN5122

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN5122 and is the answer not in the manual?

InFocus IN5122 Specifications

General IconGeneral
Matrix size0.63 \
Number of colors16.78 million colors
Native aspect ratio4:3
Projection distance- m
Projection technology3LCD
Supported aspect ratios4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)2000:1
Screen size compatibility35.4 - 358 \
Projector native resolutionXGA (1024x768)
Vertical synchronization (max)120 kHz
Vertical synchronization (min)50 kHz
Horizontal synchronization (max)106 kHz
Horizontal synchronization (min)15 kHz
FocusManual
Throw ratio1.5 - 2.5:1
Zoom capabilityYes
Focal length range- mm
Vertical lens shift range-20 - 0 °
Horizontal lens shift range-20 - 20 %
Lamp typeUHP
Lamp power245 W
Light source typeLamp
Service life of light source3000 h
Service life of light source (economic mode)5000 h
3D-
Full HDNo
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, PAL, SECAM
Supported graphics resolutions1600 x 1200 (UXGA)
RMS rated power16 W
Number of built-in speakers2
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity1
Ethernet LAN data rates10, 100 Mbit/s
Cables includedAC, RCA, VGA
Power consumption (standby)- W
Noise level32 dB
CertificationUL, c-UL, FCC, CE
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorBlack
Cable lock slot typeKensington
Operating altitude0 - 2286 m
Operating temperature (T-T)5 - 35 °C
Weight and Dimensions IconWeight and Dimensions
Depth318.5 mm
Width401 mm
Height111 mm
Weight4800 g
Package depth420 mm
Package width560 mm
Package height197 mm
Package weight8200 g
