InFocus IN5122 User Manual

81
Presentation tools
If you select the Option button on the Floating
menu, the Options window is displayed.
Optimize Performance
“LiveViewer Lite for USB” captures JPEG screenshots and sends them
to the projector. “LiveViewer Lite for USB” has two JPEG compression
options.
Transmission speed
Speed takes priority over Image quality.
The JPEG compression rate is higher.
The screen on the projector is rewritten quicker (because the
transferred data is smaller), but the image quality will be lower.
Image quality
Image quality takes priority over Speed.
The JPEG compression rate is lower.
The screen on the projector is rewritten more slowly (because the
transferred data is larger), but the image quality will be higher.
Keep PC resolution
If you remove the check mark from the [Keep PC resolution] box, your
computer's screen resolution will change per below, and the display speed
may be faster.
IN5122: 1024X768 (XGA)
IN5124: 1280 x 800 (WXGA)
If your computer does not support the display resolutions specied above,
the closest smaller supported resolution will be selected.
USB Display (continued)
Options window
About
The version information of the “LiveViewer Lite for USB”.
• When the resolution is changed, the icon arrangement on the
computer desktop screen may change.
NOTE

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
