InFocus IN5122 User Manual

49
OPTION menu
OPTION menu
From the OPTION menu, items shown in the table
below can be performed. Highlight an item using the
▲/▼ cursor buttons, and press the ► cursor or the
SELECT button to select the item (except for
RESET
LAMP HOURS and RESET FILTER HOURS)
. Then
make adjustments per the following table .
Item Description
AUTOSOURCE
Using the ▲/▼ buttons turns the automatic signal search feature on
and off.
ENABLE
ó
DISABLE
When ENABLE is selected and no signal is detected, this feature
will automatically cycle through the input ports in the following order.
The search starts from the current port. When an input is found, the
projector will stop searching and display the image.
COMPUTER IN1
ð
COMPUTER IN2
ð
LAN
ð
USB TYPE A
VIDEO

S-video

COMPONENT

HDMI

USB TYPE B
• It may take several seconds to project images from the
USB TYPE B port.
AUTO
KEYSTONE
Using the ▲/▼ buttons turns the automatic keystone feature on and
off.
ENABLE
ó
DISABLE
ENABLE
: Automatic keystone distortion correction will be
executed whenever the projector's slant is changed.
DISABLE
: This feature is disabled when OFF is selected. Select
AUTO KEYSTONE (EXECUTE) in the SETUP menu
for automatic keystone distortion correction.
• When the projector is ceiling mounted, this feature will not function
properly and therefore should be turned to DISABLE.
• This feature will be unavailable when the Transition Detector is on
(

67)
.
AC POWER ON
Using the ▲/▼ buttons turns AC POWER ON on and off.
ENABLE
ó
DISABLE
When set to ENABLE, the projector (and its lamp) will automatically turn
on when power is supplied to the projector (

17).
• If the projector is turned on via AC POWER ON but has no
signal input or user operation within approximately 30 minutes, the
projector will be turned off regardless of whether the AUTO POWER
feature
(

50) has been disabled.
(continued on next page)

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
