InFocus IN5122 User Manual

37
INPUT menu
Item Description
VIDEO
STANDARD
The video standard for the S-video port and VIDEO port can be
selected.
(1) Use the ▲/▼ buttons to
highlight the input port.
(2) Using the ◄/► buttons
switches the video standard
mode
.
AUTO
ó
NTSC
ó
PAL
ó
SECAM
N-PAL
ó
M-PAL
ó
NTSC4.43
• This feature is only for video signals from the VIDEO or S-video
ports.
• The AUTO mode automatically selects the optimum mode.
• AUTO may not work well with some signals. If the image becomes
unstable (e.g. an irregular image, lack of color), please select the
mode appropriate for the input signal.
COMPUTER IN
The computer input signal type for COMPUTER IN1 and IN2 ports
can be selected.
(1) Use the ▲/▼ buttons to highlight the desired COMPUTER IN port.
(2) Use the ◄/► buttons to select
the computer input signal type.
AUTO
ó
SYNC ON G OFF
• Selecting AUTO allows
you to input a sync on G signal or component video signal from the
port.
• In the AUTO mode, the image may be distorted with certain
input signals. In this situation, remove the signal connector so that
no signal is received and select the SYNC ON G OFF, and then
reconnect the signal.
RESOLUTION
The COMPUTER IN1 and COMPUTER IN2 input signal resolutions
can be selected for this projector.
(1) Highlight RESOLUTION from the INPUT menu using the ▲/▼
buttons and press the ► button.
The RESOLUTION menu will be
displayed.
(2) In the RESOLUTION menu, highlight
the resolution you wish to display
using the ▲/▼ buttons.
Selecting AUTO will set a resolution
appropriate to the input signal.
(3) Pressing the ► or
SELECT button when selecting a STANDARD
resolution will automatically adjust the horizontal and vertical
positions, clock phase and horizontal size.
The SOURCE_INFO dialog will display.

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
