InFocus IN5122 User Manual

9
Setting up
Connecting with your devices
Before connecting the projector to a device, consult the device’s manual to
conrm that the device is suitable for connecting with this projector and prepare
needed accessories, such as a cable in accordance with the signal of the device.
Consult your dealer if any needed accessories did not come with the product or if
the needed accessory is damaged.
After verifying that the projector and the devices are turned off, make the
connection, according to the following instructions. Refer to the illustrations on
subsequent pages.
Before connecting the projector to a network system, be sure to read the Network
Guide too.
►Only use appropriate accessories. Otherwise they may
cause a re or damage the projector and devices.
• Only use accessories specied or recommended by the projector’s
manufacturer. They may be regulated under some standard.
• Do not disassemble or modify the projector or the projector’s accessories.
• Do not use damaged accessories. Be careful not to damage the accessories.
Route a cable so that it cannot be stepped on or pinched.
WARNING
►If the cable only has a core at one end, connect the end
with the core to the projector. This may be required by EMI regulations.
CAUTION
• Plug-and-Play is a system composed of a computer, its operating system
and peripheral equipment (i.e. display devices). This projector is VESA DDC
2B compatible. Plug-and-Play can be used by connecting this projector to a
computer that is VESA DDC (display data channel) compatible.
- Take advantage of this feature by connecting a computer cable to the
COMPUTER IN1 port (DDC 2B compatible). Plug-and-Play may not work
properly if any other type of connection is attempted.
- Please use the standard drivers in your computer as this projector is a Plug-
and-Play monitor.
• The feature of some of the input ports can be selected based on your usage
requirements. Refer to the page number indicated beside each port in the
following illustration.
• Be careful not to mistakenly connect a connector to an incorrect port.
Otherwise it may cause a device or projector malfunction.
-
When connecting a connector to a port, make sure that the shape of the
connector ts the port.
- Tighten the screws to connect a connector equipped with screws to a port.
- Use cables with straight plugs, not L-shaped ones, as the input ports of the
projector are recessed.
About Plug-and-Play capability
NOTE
(continued on next page)

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
