InFocus IN5122 User Manual

18
STANDBY/ON SOURCE MENU
Operating
1.
Adjusting the volume
Use the VOLUME +/VOLUME - buttons to adjust the volume.
A dialog will appear on the screen to help you adjust the
volume. If you do not do anything, the dialog will automatically
disappear after a few seconds.
● When is selected for the current image input port, the volume adjustment is
disabled. Please see AUDIO SOURCE in the AUDIO menu (41).
● Even if the projector is in a power saving mode, the volume is adjustable
when both of the following conditions are true:
- An option other than is selected for STANDBY in the AUDIO SOURCE
item of the AUDIO menu (41).
- DISABLE is the selected POWER SAVING MODE option in the SETUP menu
(40).
● In Power Saving Mode, the volume of the microphone is adjustable with the
VOLUME +/- buttons on the remote control, in synchronization with the volume
of the projector (18).
1.
Press MUTE button on the remote control.
A dialog will appear on the screen indicating that you have muted
the sound.
To restore the sound, press the MUTE, VOLUME + or VOLUME
- button. Even if you do not do anything, the dialog will
automatically disappear after a few seconds.
Temporarily muting the sound
● When is selected for the current image input port, the sound is always
muted. Please see AUDIO SOURCE in the AUDIO menu (41).
● CLOSED CAPTIONS is automatically activated when sound is muted and
an input signal containing CLOSED CAPTIONS is received. This feature is
available only when the signal is NTSC for VIDEO or S-video, or 480i@60
for COMPONENT, COMPUTER IN1 or COMPUTER IN2, and when AUTO is
selected for DISPLAY in the CLOSED CAPTIONS menu under the SCREEN
menu (48).
1.
Press the projector or the remote's SOURCE button.
Each time you press the button, the projector switches its
input port from the current port as below.
Selecting an input signal
VOLUME +/- button
SOURCE button
MUTE button
● When AUTOSOURCE has been set to ON in the OPTION menu (49), the projector
will repeatedly check the ports in the above order until an input signal is detected.
● It may take several seconds to project the images from the USB TYPE B port.
COMPUTER IN1  COMPUTER IN2  LAN
VIDEO USB TYPE A
S-video USB TYPE B
COMPONENT (Y, Cb/Pb, Cr/Pr)

HDMI
Operating

InFocus IN5122 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 5:4, 16:9, 16:10
Contrast ratio (typical)	2000:1
Screen size compatibility	35.4 - 358 \
Projector native resolution	XGA (1024x768)
Vertical synchronization (max)	120 kHz
Vertical synchronization (min)	50 kHz
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	15 kHz
Focus	Manual
Throw ratio	1.5 - 2.5:1
Zoom capability	Yes
Focal length range	- mm
Vertical lens shift range	-20 - 0 °
Horizontal lens shift range	-20 - 20 %
Lamp type	UHP
Lamp power	245 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1600 x 1200 (UXGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Cables included	AC, RCA, VGA
Power consumption (standby)	- W
Noise level	32 dB
Certification	UL, c-UL, FCC, CE
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Operating altitude	0 - 2286 m
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	318.5 mm
Width	401 mm
Height	111 mm
Weight	4800 g
Package depth	420 mm
Package width	560 mm
Package height	197 mm
Package weight	8200 g
