Installation

27

VIDEO

InputSignal

VIDEO

OutputSignal

Connect to video equipment

• ForIN1029,IN1039,IN1049,IN1059,IN1024,IN1034,IN1044,IN1026,

IN1036,IN1046

Cablesforconnection:

• VIDEOcable*

*Thiscableisnotincluded
