trapulsPac – User Guide
Chapter 3 - Referenc
e
Object 0x1803: 4th Transmit PDO Parameter
Index 0x1803
Name 4th Transmit PDO Communication Parameter (TPDO4)
Object Code RECORD
Number of Elements 2
Value Description
Sub Index 1
Description COB-ID
Data Type Unsigned32
Access rw
PDO Mapping No
Default Value 0x480 + Node-ID
Sub Index 2
Description Transmission Type
Data Type Unsigned8
Access rw
PDO Mapping No
Default Value 1
Transmit PDO Mapping
Object 0x1A00: 1st Transmit PDO Mapping
Index 0x1A00
Name 1st Transmit PDO Mapping
Object Code RECORD
Number of Elements 0..4
Value Description
Sub Index 0
Description number of mapped objects
Data Type Unsigned8
Access rw
PDO Mapping No
Default Value 1
Sub Index 1
Description 1st mapped object
Data Type Unsigned32
Access rw
PDO Mapping No
Default Value 0x60410010 (status word)
