Ingenico FLEX IPP320 User Manual

FLEX iPP320 - Installation Guide_v1.50.docx
5
I. Required hardware
INSTALLATION TYPE
IP connection to Host +
IP connection to Point-of-sale
System
IP connection to Host +
serial connection to Point-of-sale
System
Terminal
(includes power
supply)
iPP320 PIN pad with Bell’s payment
application
iPP320 PIN pad with Bell’s payment
application
Cables
- iPP320 Ethernet cable (2 meters,
part no. 296106335)
- Network cable (3 m)
- « Magicbox » adaptor for IPP320 (2
meters, part no. 296121027)
- « null modem » serial cable (2 meters,
part no. DB9-M/FSPEC-10)
Documentation
- User guide
- “Introduction to the chip card” brochure
Cards
- Credit test card (magnetic stripe)
- Credit test card (chip)
- Debit test card (magnetic stripe)
- Debit test card (chip)

Ingenico FLEX IPP320 Specifications

General

Connectivity	Ethernet
Card Reader	Magnetic Stripe
Protocols	IP
Payment Methods	Contactless
Power Supply	Via Ethernet or external power adapter
Operating Temperature	0°C to +40°C
