III. Starting up the terminal
This section describes the steps for starting up the FLEX IPP320 PIN pad. It contains the procedure for
validating the device configuration and initializing the Payment Terminal as well as for downloading
and activating the required application.
1. Checking the PIN pad configuration
These steps allow you to confirm the terminal preconfiguration for communication mode (to
the host and to the Point-of-sale System) and for identification to the Desjardins host.
o Check the terminal identification (terminal number)
• On the idle screen, if «MENU» is not displayed above the F1 key, press the
yellow key followed by the “0” key to unlock the terminal menus.
• Press F1, the terminal displays (Main menu) screen.
• Select (Configuration) then press the green key, the terminal displays
(Configuration) screen.
• Using F2 or F3 to navigate, select (Config. report) and press the green key.
• Select (Merchant Info) and press the green key.
• The terminal displays configuration data related to the merchant’s
identification. To validate the PIN pad’s configured terminal number, look at
the line that starts with RETLRxxxxxxyy (it may be necessary to scroll down
using the F2 key in order to see this line). See Appendix A for details.
o Check the host communication mode
• On the idle screen, if «MENU» is not displayed above the F1 key, press the
yellow key followed by the “0” key to unlock the terminal menus.
• Press F1, the terminal displays (Main menu) screen.
• Select (Configuration) then press the green key, the terminal displays
(Configuration) screen.
• Using F2 or F3 to navigate, select (Config. report) and press the green key.
• Select (Modem & Network) then press the green key.
• The terminal displays the current host communication parameters (scrolling
with F2 key might be necessary; see Appendix A for details).
