10.5 Switching to Programming Mode (SSP)
If fitted remove the Payout or Ticket modules. Power the NV200, once the unit has
initialised toggle dip-switch 8 up and down.
To switch the unit back repeat the procedure explained above.
WARNING!
Risk of unit damage
When in programming mode and performing an
update, do not turn off the power before the
operation is complete as this could make the unit
unusable.
10.6 Changing the cashbox flag in the NV200
If the NV200 is configured for the wrong cashbox this is changed using validator
manager, connect to the unit as outlined in Section 6.3.1; navigate to the ‘Options’
tab, select Cashbox Type from the right hand side and select the appropriate
cashbox from the dropdown. Click apply changes; the unit will reset with the
applicable cashbox setting.
10.7 Free Fall Cashbox Advice
The NV200 cashbox and TEBS cash bag have been designed to remain intact after
an impact of 75cm onto a concrete floor. Dropping the cashbox multiple times can
result in physical damage to the cashbox/bag.
10.8 ccTalk DES Encryption – Trusted Mode
Ensure the NV200 has been configured to use DES encryption in Validator Manager,
this setting can be found on the options tab. To pair the NV200 with a DES trusted
machine please follow the steps below:
1. Remove power from the unit then remove the cashbox
1. Re-power the unit, once the unit has started it should be in pairing mode.
If a Smart Payout module is connected the unit must be empty before it can pair to the host.
10.9 Escrow
The NV200 has a single note escrow facility. This allows the NV200 to hold onto the
note once validated, and only stack the note into a cashbox when the host machine
confirms that the Vend operation has been completed. If no confirmation of the
Vend is received, the note will be returned to the user after 30 seconds.
If the host machine itself aborts the transaction by sending the reject command
(0x08). Similar commands can be sent depending on the protocol used. For
information relating to other protocols please contact support.
10.9.1 Multi-Escrow
When the Payout module is used it adds the ability to store up-to 20 notes in
escrow, this is done by dynamically allocating certain positions on the tape to
escrow. As slots are assigned dynamically it means when the transaction is
completed notes don’t need to move to a different location thus the speed of the
unit isn’t affected.
For more details on the multi-escrow functionality please contact our support team.
