3 TECHNICAL DATA
3.1 Dimensions
Drawings of all configurations for the NV200 can be found in Appendix 10.1.
3D drawings in .stp form are also available upon request from our support team.
3.2 Weight
NV200 with Standard Bezel
1.1 kg
Cashbox Options
500n with Chassis
Empty: 1.76kg
Full: 2.21kg
1000n with Chassis
Empty: 1.94kg
Full: 2.84kg
TEBS Cashbox
Empty: 6.7kg
Full: 7.5kg
Modules
Payout Module
Empty: 2.54kg
Full: 2.6kg
Ticket Module:
Empty: 1.34kg
Full: 2.64kg
The ‘full weight’ was taken with a random sample of street grade GBP notes
3.3 Environmental Requirements
Environment
Minimum
Maximum
Maximum Change
per Hour
Temperature
+5°C / 37.4°F
+50°C / 122°F
1° per hour
Humidity
5%
95% Non-condensing
2% per hour
