Before being inserted into the printer with the TABS facing towards the NV200.
4.5 Lock Mounting
4.5.1 Lock Fitting – NV200
The Lock can be fitted to the front of
the NV200 replacing the silver front
plate (shown to the right) which ships
by default.
Before the lock can be installed,
remove the NV200 from the cashbox
chassis. Lift the latch, slide the head
forward and lift the head away from
the chassis.
