4.4.1.2 Rear
The Roll is inserted into the Rear holder with the paper wrapping round the
underside of the printer, before passing underneath the metal positioning arm and
into the printer, as shown in the pictures below.
4.4.2 Fan Fold
The Fan Fold Tickets Has TABS printed onto the Ticket that must be used to
determine the correct orientation of the Ticket, the image below shows the TABS.
4.4.2.1 Top
The Fan Fold Tickets are inserted into the printer with the TABS on the leading edge.
