8.3.1 NV200 Connections
Ensure the NV200 has
power applied, the pin-
outs for the relevant
connection can be found
in Section 5.2.2.
The NV200 connector and the
IF17 connector are similar,
the only difference is the
power cables in pins 15 & 16
on the NV200 connector.
8.3.2 TEBS Connections:
Ensure both the NV200
and TEBS cashbox have
power applied, the pin-
outs for the relevant
connection can be found in
Section 5.2.2.
The NV200 connector and the
IF17 connector are similar, the
only difference is the power
cables in pins 15 & 16 on the
NV200 connector.
