The TEBS cashbox and Ticket module require the unit is run at 24v (±10%).
3.4.2 Supply Currents
The supply current required to run the NV200 will vary during the phases of
operation. Below is a table detailing the required current information.
To use the extra modules such as the payout or ticket module additional power is
required. The table below explains the additional current draw required.
*Maximum current required to print a solid black ticket
For a NV200 with a TEBS cashbox and payout module, the peak current draw would
be:
3A + 2.6A + 2A = 7.6A
For more detailed power information energy profiles for the various stages of
operation can be found in Appendix 10.2.
3.4.3 Power Supply Guidance
Please check the power requirements of your host machine and other peripherals to
dimension a suitable power environment for your machine setup.
TDK Lambda manufactures suitable power supplies for the NV200. Please see table
below for further details.
