5. Once all the bank notes have been transferred to
the Transaction Drum move the Diverter into the
payout position by gently turning the Allen key
clockwise until it reaches the dead stop.
6. Pay out the stored bank notes by turning the
Allen key anti-clockwise. The barcode will be
travelling into the Payout module and the bank
notes will be paid out through the note exit.
