Integra CUSA Clarity User Manual

CUSA
®
Clarity Ultrasonic Surgical Aspirator System Operator’s Manual
A-3
Handpiece
Ultrasonic
Frequency
35.55 - 36.25 kHz
(frequency range)
Maximum Tip Amplitude
(High Frequency Handpiece)
Up to 210 microns
Fluidic System
Irrigation Rate
• The irrigation rate display
shows digits 2 to 20.
• The irrigation rate is
approximately:
Suction System
• Up to 640 mm (25.2 in)
mercury at the pump intake at
sea level.
• The suction level is lower at
higher altitudes.
Dimensions
Length 13.03 cm (5.13 in)
Diameter 2.41 cm (0.95 in)
Weight 71 g (0.15 lb)
Cable Length 463.3 cm (182.4 in)
Frequency
High 36 kHz
Handpiece
Subsystems
• Normal = 2 to 20 ml/min
• Fast Flush = 25 ml/min

Integra CUSA Clarity Specifications

General

Brand	Integra
Model	CUSA Clarity
Category	Medical Equipment
Language	English
