Clarity Ultrasonic Surgical Aspirator System Operator’s Manual
A-4
Electrical Requirements
Electrical Requirements
Power Cords
Power Input and Fusing
Voltage 100-240V~
Frequency 50-60Hz
Power 480VA
Phases 1
Class 1
Fuses
5A, Type T, 1500A IR, 250V, 5mm x
20mm, ceramic body
Plug variation by country:
Australia AS3112, Straight
Brazil NBR 14136, Straight
China GB2099, Straight
Europe CEE 7/ XVII, Straight
Italy CEI 23-50, Straight
Japan JIS 8303, Straight
South Africa SANS 164-1, Straight
Switzerland SEV Typ 12, Straight
United Kingdom BS 1363, 13A fused, Angled
Only use Integra approved power cords.
United States and Canada:
Meets hospital grade UL817
Cord 3 x 16AWG 5 Meters Color White
Console Connector C13 IEC 60320-1 V-Lock
Plug NIMA 5-15 Straight
Other Countries:
Cord 3 x 1mm
2
5 Meters Color Black
Console Connector C13 IEC 60320-1 V-Lock
NOTE
Only the exact fuse type and rating is to be used.
Littelfuse 0215005.HXP, 2 fuses required per console.
