VIAFLO 96/384 – Operating instructions V11 Installation
www.integra-biosciences.com 17
NOTE
Extending the volume range is not recommended. Full functionality and
specified accuracy/precision cannot be guaranteed.
Handle Sen-
sitivity
Sets the sensitivity of the control unit to move the
pipetting unit and base unit.
• Use the Touch wheel to set a sensitivity 1 (low) to 9
(high). Press OK.
1-9
Sound Select an option and press OK to change the status of
the beep tone between On and Off:
• Step Complete: at the end of a program step
• Program Complete: at program completion
• Purge Key: when PURGE is pressed.
• Messages: when a message appears.
• Error Message: when an error message appears or
when illegal data entry is attempted.
• Touch Wheel: When spinning the Touch wheel.
• Last dispense: before the last dispense in Repeat
Dispense and Variable Dispense.
/
(On/Off)
Display
Brightness
Sets brightness of the display. Use the Touch wheel to
change the brightness: 1 (dim) to 10 (bright). Press OK.
1-10
Main Menu Select a function to be hidden from the main menu (Off)
and press OK:
• Pipet, Repeat Dispense, Dilute, Pipet/Mix, etc.
• The Automatic mode is by default deactivated. To acti-
vate it, change the status to “” (On). See section 5.3.3
for a description of the Automatic mode.
/
(On/Off)
Touch
Wheel
Adjust your Touch wheel spin sensitivity. Low, Medium,
High
Pipetting Select an option and press OK.
• Purge Key Speed: Choose the desired purge speed.
• Blowin Delay: Choose a timed delay between the
blowout and the blowin at the end of a dispense, if no
two step blowout is performed, see “4.3.3
Blowout
modes” on page 23.
• Extend Volume (not available for 12.5 µl pipetting
head): For pipetting below the volume range specified:
50 μl pipette: (1.0)–2–50 μl
125 μl pipette: (2.0)–5–125 μl
300 μl pipette: (5.0)–10–300–(310) μl
1250 μl pipette: (25)–50–1250 μl
The volumes in brackets refer to extended volumes,
e.g. extend the minimal pipetting volume of a 125 μl
head from 5 μl to 2 μl.
1-10
None/
0.5-5.0 s
/
(On/Off)
