CHAPTER 4 Intel Express 460T Standalone Switch Users Guide
Tag-based VLAN
You configure a tag-based VLAN by configuring port membership and
ingress/egress rules. If any of your devices don’t support 802.1Q VLAN
tags, additional configuration may be necessary.
To configure a tag-based (IEEE 802.1Q) VLAN
1 Create a VLAN and assign member ports.
a Click the Configure VLAN menu and then click Tag-based (IEEE
802.1Q) VLAN.
b On the main Tag-based VLAN page, click Add to create a new VLAN.
To modify an existing VLAN, click the VLAN name and click Edit.
c If you are creating a new VLAN, type a name and VID (from 2 to 4094)
to identify it.
d To add a port to the VLAN, click the port in the Available ports box
and click Add. To remove a port, click the port in the Member ports
box and click Remove.
e The switch supports up to 12 IGMP Snooping sessions to manage
broadcast traffic. To make the VLAN be part of an IGMP Snooping
session, select the Enable IGMP Snooping check box.
f When you finish adding ports, click Next.
