Table 5. Development Kit Feature Set Summary
Description
Comments
Processor
Intel
®
Core™ i5
Soldered to board
Chipset
Intel
®
5 Series Chipset
1071 pin BGA footprint
Memory
Two DDR3 DIMM slots
Maximum 8GB of DDR Memory (RAM) of
ECC and non-ECC using 2Gb
1
technology
Supports DDR3 frequency of up to
1066MT/s
Notes:
4Gb (x16 width only) technology support is
under investigation
External
Graphics
PCIe* Slot
One x16 PCIe slot supported.
2x8 PCIe* supported through Nowata Add-
in card.
eDP supported through PCI graphics add-in
card
Video
24-bit dual channel LVDS
Interface
Connectors and cables from previous
development kits can be used.
Display Ports
3 – Display port Lanes on Chipset. 1 On-
Board DP Connector. Other 2 ports can be
supported through PCI graphics add-in card.
CRT
On Board right-angled CRT Connector
Similar to the earlier platforms
HDMI
1 On-Board HDMI Connector (Optional
Routing through Display Port D of Chipset).
Three additional HDMI ports are available
through the Eaglemont 2 external card.
PCI
Three 5V PCI slots supported
through PCI extension card.
PCI revision 2.3 compliant (33MHz)
No PCI slots on motherboard, only one
goldfinger on board.
PCI
Express*
8 PCIe lanes
PCI Express 2.0 base revision compliance
Five lanes to x1 PCIe ports
One lane to LAN
Two Lanes to Docking
On-Board
LAN
Intel
®
82577 Gigabit Ethernet PHY
BIOS (SPI)
2x SPI flash devices
Support for multi vendor SPI
Support multi package (SOIC-8 and
SOIC-16)
ATA/
Storage
6 SATA Ports
2 Cable Connector and 1 Direct Connect
Connector. 2 eSATA connectors and 1 to
docking. RAID 0/1 support.
