Intel Intel® Core i7 User Manual

58 323094 Dev Kit Manual
4.6.2.7 HAD Header for External HDMI Support
Table 33. HAD Header for External HDMI Support (J8F1)
Pin
Signal
Definition
1
GND
Ground
2
N/C
Reserved
3
+V3.3
3.3 volt supply
4
HDA_SDIN3_R2
SDIN3 R2
5
N/C
Reserved
6
HDA_SDIN3_R1
SDIN3 R1
7
VBATS_HDA_R2
6V – 14.1V supply
8
HDA_SDIN2_R
SDIN2
9
+V3.3
3.3V
10
HDA_CODEC_3_SDATAOUT
SDATAOUT
11
GND
Ground
12
HDA_CODEC_3_SYNC
Synch
13
V3.3A_1.5A_HDA_IO
3.3 volt supply
14
HDA_CODEC_3_RST#
Reset
15
GND
Ground
16
HDA_CODEC_3_CLK
Clock
4.6.2.8 Front Panel Power State Header
Table 34. LED Header (J8G3)
Pin
Signal
Definition
1
V3.3M
3.3 volt supply
2
PP_S3CLEDSW
S3 Cold LED
3
PP_S5LED
S5 LED
4
PP_S0_LEDSW
S0 LED
5
GND
Ground
6
PP_S4_LEDSW2
S4 LED
7
PP_S3CLED
S3 Cold LED
8
PP_S4LEDSW1
S4 LED
