Intel Intel® Core i7 User Manual

Dev Kit Manual 59 323094
4.6.2.9 Descriptor Security Override
Table 35. Descriptor Security Override (J8F4)
Pin
Signal
Definition
1
GND
Ground
2
GND
Ground
3
SMC_LID
SMC Lid
4
VIRTUAL_DOCK_DET#
Virtual Docking
5
N/C
Reserved
6
GND
Ground
7
HDA_DOCK_EN#
HAD Docking
8
BIOS_REC
BIOS Recovery
9
GND
Ground
10
GND
Ground
11
VIRTUAL_BATTERY
Virtual Battery
12
HYBRID_GFX_SW
Switchable Graphics
13
GND
Ground
14
GND
Ground
15
RTC_RST#
RTC Reset
16
N/C
Reserved
4.6.2.10 Controller Link Header
Table 36. Controller Link Header (J8G2)
Pin
Signal
Definition
1
GND
Ground
2
+V5A
5 volt supply
3
CL_CLK
Controller Link Clock
4
GND
Ground
5
GND
Ground
6
+V3.3A_H
3.3 volt supply
7
CL_DATA
Controller Link Data
8
CL_RST#
Controller Link Reset
9
GND
Ground
10
GND
Ground
