Intel Intel® Core i7 User Manual

Dev Kit Manual 61 323094
Pin
Signal
9
D_LFRAME#
10
D_LDRQ1
11
LPCD_SMC_EXTSMI#
12
LPCD_PD#
13
D_CLKRUN
14
D_SER_IRQ
15
KSC_LPC_DOCK#
16
LPCD_RST#
17
N/C
18
GND
19
N/C
20
LPCD_OPNREQ#
21
GND
22
GND
23
D_CLK_33
24
D_CLK_14
4.6.2.13 LPC Side Band Header
Table 39. LPC Side Band Header (J9G2)
Pin
Signal
1
PM_PWRBTN#
2
ALL_SYS_PWRGD
3
PM_RSMRST#
4
IMVP_VR_ON
5
PM_SLP_S5#
6
CPU_PWM_FAN
7
PM_BATLOW#
8
CPU_TACHO_FAN
9
PM_SLP_S3#
10
ATX_DETECT#
11
PM_SLP_S4#
12
SML1_DATA
13
N/C
14
SML1_CLK
