4 Development Board Physical
Hardware Reference
This section provides reference information on the physical hardware, including component‟s
locations, connector pinout information and jumper settings.
4.1 Primary Features
Figure 7 and Figure 8 show the major components of the motherboard, top and bottom views
respectively). Table 16 gives a brief description of each component.
Figure 7. Component Locations – Top View
