Dev Kit Manual 45 323094
Figure 8. Component Locations – Bottom View
Table 16. Component Location
Item
Description
1
SMSC IO
2
PCIe* Slot 6 (No_Stuff)
3
Infra red port
4
LAN Docking switch
5
PCIe Slot3
6
PCIe Slot 4
