46 323094 Dev Kit Manual
Item
Description
7
PCI-e Slot 5
8
DP Docking Switch
9
RS232 Transceiver
10
PCIe Slot 1
11
PCIe Slot 2
12
Chipset JTAG Buffer
13
Onboard display port
14
HDMI LVL translator
15
Onboard HDMI port
16
CPU core VID Override jumper
17
GFx core VID Override jumper
18
Processor XDP
19
CPU heat sink on top of the
Processor
20
Power Button
21
Reset button
22
Processor
23
AC Jack
24
System VR
25
Front Panel Header
26
RTC Battery holder
27
USB FPIOs
28
USB FPIOs
29
Chipset XDP
30
Virtual Battery Switch
31
EC/KSC
32
Lid Switch
33
Virtual docking Switch
34
LPC Slot
35
Chipset
36
LPC side band
37
Scan Matrix
38
LPC Hot Dock
39
SPI Programming Header
40
SPI Devices
