Intel Intel® Core i7 User Manual

52 323094 Dev Kit Manual
Table 20. Power-on and Reset Push Buttons
Item
Description
Ref
Des
1
Power Button
SW1E1
2
Reset Button
SW1E2
3
CPU
U3E1
4.5 LEDs
The following LEDs in Table 21 provide status of various functions:
Table 21. Development lit LEDs
Function
Reference
Designator
Page# on the
Schematics for
reference
SATA ACTIVITY
CR7G1
16
MPC ON/OFF Indicator
CR6D1
18
BRAIDWOOD R/B#
CR7G2
27
VID0
CR1B1
46
VID1
CR1B2
46
VID2
CR1B3
46
VID3
CR1B4
46
VID4
CR1B5
46
VID5
CR1B6
46
VID6
CR1B7
46
NUM LOCK
CR9G2
47
CAPS LOCK
CR9G3
47
SCROLL LOCK
CR9G1
47
S4
CR5G6
65
S5
CR5G7
65
M0/M3
CR5G3
65
S3 COLD
CR5G5
65
S0
CR5G4
65
DSW
CR5G2
65
SYSTEM POWER GOOD
CR5G8
65
