Dev Kit Manual 27 323094
Raw Card D single rank x8 unbuffered ECC
Raw Card E dual rank x8 unbuffered ECC
Raw Card F - dual rank x16 unbuffered non-ECC
Table 6. Supported DIMM Module Configurations
Raw
Card
Version
DIMM
Capacity
DRAM
Device
Technology
DRAM
Organization
# of
DRAM
Devices
# of
Physical
Device
Ranks
# of
Row/Col
Address
Bits
# of
Banks
Inside
DRAM
Page
Size
A
512 MB
512 Mb
64 M x 8
8
1
13/10
8
8K
1 GB
1 Gb
128 M x 8
8
1
14/10
8
8K
2 GB
2 Gb
256M x 8
8
1
15/10
8
8K
B
1 GB
512 Mb
64 M x 8
16
2
13/10
8
8K
2 GB
1 Gb
128 M x 8
16
2
14/10
8
8K
4 GB
2 Gb
256M x 8
16
2
15/10
8
8K
C
256 MB
512 Mb
32M x 16
4
1
12/10
8
8K
512 MB
1 Gb
64 M x 8
4
1
13/10
8
8K
1 GB
2 Gb
128 M x 16
4
1
14/10
8
8K
2 GB
4 Gb
1
256M x 16
4
1
15/10
8
8K
D
512 MB
512 Mb
64 M x 8
9
1
13/10
8
8K
1 GB
1 Gb
128 M x 8
9
1
14/10
8
8K
2 GB
2 Gb
256M x 8
9
1
15/10
8
8K
E
1 GB
512 Mb
64 M x 8
18
2
13/10
8
8K
2 GB
1 Gb
128 M x 8
18
2
14/10
8
8K
4 GB
2 Gb
256M x 8
18
2
15/10
8
8K
F
512 MB
512 Mb
32M x 16
8
2
12/10
8
8K
1 GB
1 Gb
64 M x 16
8
2
13/10
8
8K
2 GB
2 Gb
128 M x 16
8
2
14/10
8
8K
4 GB
4 Gb
1
256M x 16
8
2
15/10
8
8K
Note: 1. 4 Gb technology support is under investigation pending availability of DRAM silicon.
3.7.1.7 Processor PCI Express* Support (PCI Express Graphics)
The processor supports a PCI Express* port, which can be used for PCI Express Graphics
(PEG) or for PCI Express IO. The development kit supports external graphics through this
processor PEG slot, and supports Lane-Reversal of the PEG lanes. However, the motherboard
uses non-reversed routing.
The processor has the capability of using the PCI Express interface in two ways:
1 x16 PCI Express IO (or PEG)
