Dev Kit Manual 55 323094
Pin
Signal
Definition
3
SATA_LED#
Indicates PATA or SATA activity Active Low
4
GND
Ground
5
GND
Ground
6
PWR_CONN_D
System Power Active Low
7
RST_PUSH#_D
System Reset Active Low
8
GND
Ground
9
+V5
5 volt supply
10
N/C
No Connect
11
N/C
No Connect
12
GND
Ground
13
GND
Ground
14
Reserved
15
PS_LATCH#
16
+V5
5 volt supply
4.6.2.3 eDP Support (J6D1)
Table 26. eDP Support Connector
Pin
Signal
Definition
1
+V5
5 volt supply
2
L_BKLT_EN
LVDS Backlight Enable
3
DBL_CLK
Double Clock
4
L_BRIGHTNESS
Brightness
5
N/C
Reserved
6
LVDS_VDD_EN
LVDS VDD Enable
7
SMB_THRM_DATA
Thermal Data
8
GND
Ground
9
SMB_THRM_CLK
Thermal Clock
10
ALS_INTR#
Interrupt
4.6.2.4 SATA Pinout
Table 27. SATA Port 0 ‘Direct Connect’ Connector Pinout (J8J1)
Pin
Signal
2
TX
