Intel Intel® Core i7 - Table 28. SATA Ports 1 and 2;Esata Ports 3 and 4 Pinout (J7 G2, J7 G1, J6 J1, J7 J1); Table 29. SATA Power Connector (J6 H1); Table 30. SPI Programming Header (J8 E1)

56 323094 Dev Kit Manual
Pin
Signal
3
TX#
5
RX#
6
RX
8, 9, 10
+3.3V
14, 15, 16
+5V
20, 21 ,22
+12V
1, 4, 7, 11
GND
12, 13, 17, 19
GND
Table 28. SATA Ports 1 and 2/eSATA Ports 3 and 4 Pinout (J7G2, J7G1, J6J1, J7J1)
Pin
Signal
2
TX
3
TX#
5
RX#
6
RX
1, 4, 7
GND
Table 29. SATA Power Connector (J6H1)
Pin
Signal
1, 2
+3.3V
3, 4
+V5V
5
+V12
6, 7, 8, 9, 10
GND
4.6.2.5 SPI Programming Header
Table 30. SPI Programming Header (J8E1)
Pin
Signal
Definition
1
V3.3M_SPI_CON
3.3 volt supply
2
GND
Ground
3
SPI_CS#
Chip Select
4
SPI_CLK_SW
Clock
5
SPI_SO_SW
Signal Out
6
SPI_SI_SW
Signal In
7
PCH_GPIO60_INT#
Finger Print Interrupt
