Intel Intel® Core i7 User Manual

40 323094 Dev Kit Manual
Voltage Rail Name
REFDES of the
Power Measurement Resistor
+VDC_PHASE
R3B23
+V1.05S_PCH_VCC
R6U15
MAX8792_V1.05SVTT_LX_L
R4F1
MAX8792_V1.05M_LX_L
R6E8
+V5S_HDMID_OB
R2A2
1.5_VIN
R3W26
+V3.3S_DP_OB
R5N1
+V5A_USBPWR_IN
R3A1
+V1.05S_VCC_SA
R4D10
+V3.3A_MBL
R4H1
+V1.8S_VCCSFR
R4D4
MAX8792_V1.1SVTT_VIN
R5G1
+V1.05S_VCCTT
R4R2
-V12A
R4H7
+V5SB_ATXA
R4H8
+V1.05S_VCC_PEG_DMI
R4D9
+V1.8S
R5E1
+V12S_PEG
R5N2
+V3.3S_PEG
R5C2
62290_VIN
R5E5
+V12S_SATA_P1
R5W9
+V3.3S_PCIESLOT2
R6P1
+V3.3S_PCIESLOT1
R6B5
+V12S_PCIESLOT1
R6B2
+V12S_PCIESLOT5
R6N1
MAX8792_V1.05M_VIN
R6T4
+V5S_LVDS_BKLT
R7D11
+V3.3_PCIESLOT3
R7C1
+V3.3_PCIESLOT4
R7R2
+V12S_PCIESLOT3
R7N1
+V3.3S_PCIESLOT5
R7B6
+V3.3M_LAN
R7A1
+V3.3S_LVDS_DDC
R7R12
+V12S_PCIESLOT4
R7P5
