42 323094 Dev Kit Manual
Voltage Rail Name
REFDES of the
Power Measurement Resistor
+V3.3S_SATA_P1
R6W18
+V1.1S_VCC_SATA
R7V2
+V3.3S_SIO
R9M10
+V3.3_KBCS
R9E6
51125_VIN
R5G6
+V5S_IMVP6
R3B20
+V3.3S_DIMM1
R2G15
+V3.3S_DIMM0
R2G4
+V1.05S_VCC_DMI
R6U19
+VCCA_DPLL_L
R6E9
+V3.3S_VCCA3GBG
R6U10
+V3.3S_CRT_VCCA_DAC
R7E15
+V3.3M_VCCPEP
R7U17
+V_NVRAM_VCCPNAND
R7V1
+V1.0M_LAN
R7A8
+V3.3A_VCCPUSB
R7F3
+V1.5S_1.8S_VCCADMI_VRM
R6U11
+VCCAFDI_VRM
R6U13
+VCCPLLVRM
R6U14
+V1.1S_PCH_VCCDPLL_EXP
R6U16
+V1.05S_VCCPCPU
R6U17
+V1.05S_VCCDPLL_FDI
R6F14
+V3.3M_LAN_OUT_R
R7A10
+V1.05S_VCCUSBCORE
R7F4
+V1.8S_VCCTX_LVD
R7T33
+V3.3S_VCCA_LVD
R7U1
+V3.3S_VCC_GIO
R7U2
+V1.05S_SSCVCC
R7T14
+V3.3A_1.5A_VCCPAZSUS
R7U8
+V1.05M_VCCAUX
R7U9
+V3.3S_VCCPCORE
R7U11
+V3.3A_VCCPSUS
R8F12
