Intel Notebook

Modules & Options
7 - 22 3.5G Module
7
8. Insert the USIM card as illustrated in (Figure 7 - 17) and close the SIMLOCK.
9. Close the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 18.
10. Replace the hard disk assembly, cover, screws and battery etc.
Figure 7 - 17
Insert the USIM
Card
Figure 7 - 18
SIMLOCK Lock
