1 - 16 System Map: Left & Right Views
Quick Start Guide
1
System Map: Left & Right Views
Figure 1 - 8
Left & Right Views
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor
Port
4. Vent/Fan Intake/
Outlet
5. 3 * USB 2.0 Ports
6. ExpressCard Slot
(see page 2 - 7)
7. Optical Device
Drive Bay (for CD/
DVD Device - see
page 2 - 3)
8. RJ-11 Phone Jack
9. Security Lock Slot
1
4
2
7
8
3
5
5

Overheating
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in-
take(s) while the computer is in use.
5
9
6
Model A
Model B
4
1
2
3
55
6
7
5
8
9
Model A
Model B
