System Map: Front & Rear Views 1 - 15
Quick Start Guide
1
System Map: Front & Rear Views
Figure 1 - 7
Front & Rear Views
1. LED Power & Com-
munication Indica-
tors
2. 7-in-1 Card Reader
3. S/PDIF-Out Jack
4. Microphone-In Jack
5. Headphone-Out
Jack
6. Battery
1
43 5
2
7-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro) / MS Duo (requires PC adapter) /
Mini SD (requires PC adapter) / RS MMC (requires PC adapter)
6
Model A
1
43 5
2
Model B
Model A
Model B
6
To Next Page
