Intel Notebook

Upgrading The Computer
Upgrading the Hard Disk Drive 6 - 5
6
5. Lift the hard disk up in the direction of arrow .
6. Remove the screws & and cover .
7. Reverse the process to install a new hard disk drive.
Figure 6 - 3
HDD & Cover
Removal
5
6 7 8
5
7
6
8
