Specification
Antenna System
Antenna Radome Height 1454 mm (57.44")
Antenna Radome Diameter Ø1379 mm (54.29")
Antenna Reector Diameter Ø1050 mm (41.33")
Antenna Unit Weight (With Radome) 113 kg (249.12 Ibs)
Platform 3-axis: Azimuth, Elevation, Cross-level
Positioning
3-axis Velocity Mode Servo Control:
Azimuth, Elevation, Cross-Level
Azimuth Range Unlimited
Elevation Range -20° to +115°
Cross-level Range Up to ±37º
Stabilization Accuracy 0.2° peak mispointing @ max ship motion condition
Motor Brake System Dynamic braking
Ship's motion
Roll ±25° at 6 second
Pitch ±15° at 6 second
Yaw ±8° at 6 second
Turning rate Up to 12°/sec & 5°/sec
RX
Frequency 10.7 GHz ~ 12.75 GHz Ku-band
Gain 40.7 dBi @ 11.7 GHz (without radome)
Tx
Frequency 13.75 GHz ~ 14.5 GHz Ku-band
Gain 42.0 dBi @ 14.25 GHz (without radome)
Above Deck IFL Termination
1 x 50 N-type female connector
TX, RX: 10 MHz/50 MHz, 400 MHz, 433 MHz
L-band (950 MHz ~ 2150 MHz)
DC power to BUC & pedestal (and LNB)
G/T over Rx Range
at elevation angle Min. 30 deg.
Min. 20.0 dB/K @ 12.75 GHz (without radome)
Polarization Linear (X-pol, Co-pol)
BUC NJRC 8 W (standard), 16 W, 25 W (optional)
LNB Intellian PLL LNB
ACU to ADU Cable (Antenna Cable)
Single 50 coax cable for Rx, Tx, FSK, Reference and Power
from ACU to ADU
Input power 48 V DC (max 500 W) through Rx, Tx RF Cable
Antenna Control Unit (ACU)
ACU Size 431 mm x 350 mm x 44.3 mm
ACU Weight 5.2 Kg
Display 256 x 64 Graphic OLED
Key Two Push Keys
LED Indicator Three LEDs for Power, Tracking and Error
USB Port 2 ea (front panel), 1 ea (rear panel, for Wi-Fi dongle)
Ship's Gyrocompass Interface NMEA 2000, NMEA 0183 (GYRO)
