Planning Installation
ACU Box (Including Components Kit)
Before beginning installation, make sure you have all the included components.
Description Q'ty Size Remarks
Antenna Control Unit (ACU) 1
431 mm x 350 mm x
44.3 mm
Antenna Control Unit (ACU)
Quick Installation Guide (QIG) 1
RF Hazard Sticker 1 Radiation Safety Distance (15 m) Label
Mounting Template 1
ACU Rack Mount Bracket 2 To x ACU to 19inch Rack Frame
Flat Head Screw 10 M4 x 12 L Bolt Kit for Rack Type Mount Bracket
USB Cable (A-A) 1 1.8 m ACU (Front Panel) to PC
AC Power Cord (CEEE7/7) 1 1.5 m ACU Power (220 V)
RG-6 RF Cable 2 1 m ACU to Modem
Modem Interface Cable
(For iDirect Modem)
1 1.5 m ACU to Modem (iDirect Modem)
Ethernet Cable (RJ45/LAN) 2 1 m ACU to PC/Intellian M&C
Wi-Fi Dongle 1
Hex Bolt (BUMAX) 5 M12 x 80 L
Bolt Kit for Antenna - Deck (Mast)
Assembly (1 spare set included)
Flat Washer 5 M12
Spring Washer 5 M12
Hex Head Wrench Bolt 5 M6 x 40 L
Spare Bolt Kit for Radome AssemblySpring Washer and Flat Washer 5 M6
Sems Bolt 2 M4 x 8 L
Radome Door Key 2 Two Door Keys
Waterproof Foam 1 X-shape Cable Hole Type
